CB500F 2021

£5,699.00

Make an Enquiry Test Ride Enquiry Part Exchange Enquiry
Return to Model Categories

CB500F 2021 Promotions

Find out more

Model Description


One look. It takes just one look for your entire body to become one with the CB500F. It was built for you and you know it. You smile. You radiate confidence, boosted by the bike’s stripped-down, aggressive silhouette and fierce styling. The road is wide open. And all yours.

PURE FORM

Pure thrill. Undiluted.
The CB500F is motorcycling stripped back to its purest state. The tightly-wrapped, aggressive style shows off the machine’s parallel twin-cylinder engine and wide, tapered handlebars give it a streetfighter’s signature. The sculpted fuel tank cuts down on bulk, and provides ample capacity, allowing you more time on the road. And sharp new graphics stand out from the stunning paint, whatever colour you choose.

MOVING UP

The best of both worlds.
Rapidly accelerating from a standing start at a traffic light, or racing through the slick six-speed gearbox at high rpm out on the open road: the CB500F offers you an infinite new playground.

Model Specification


  • Engine

    Engine Type

    Liquid-cooled 4-stroke DOHC parallel twin

    Engine Displacement

    471cc

    Bore and Stroke

    67mm x 66.8mm

    Carburation

    PGM-FI electronic fuel injection

    Compression Ratio

    10.7:1

    Ignition

    Starter

    Electric

    Oil Capacity

  • Performance

    Max Torque

    43Nm / 6500 rpm

    Max Power

    35kW / 8600rpm

  • Dimensions

    Length x Width x Height

    Wheelbase

    1,410mm

    Ground Clearance

    145mm

    Seat Height

    789mm

    Fuel Capacity

    17.1 L

    Tyres Front

    120/70ZR-17M/C

    Tyres Rear

    160/60ZR-17M/C

    Brakes Front

    320 mm x 5 mm disc with two piston caliper

    Brakes Rear

    240 mm x 5 mm disc with single piston caliper

    Dimensions

    Kerb Weight

    189kg

    Dry Weight

  • Wheels

    Suspension Front

    Conventional Telescopic, 41mm, pre-load adjustable

    Suspension Rear

    Prolink mono with 5 stage pre-load adjuster, steel square pipe swingarm

    Wheels Front

    Multi-Spoke Cast Aluminium

    Wheels Rear

    Multi-Spoke Cast Aluminium

  • Transmission

    Transmission

    Gearbox

    6-speed

    Final Drive

    Chain

    Transmission Type

  • Frame

    Frame Type

    Steel diamond
