MSX125 2018 Promotions


Model Description


ATTITUDE REDESIGNED

“Mini-Streetfighter” Feel
In 2013, the MSX125 (Mini Street X-Treme 125) was developed for a new generation of young riders.

A thorough redesign in 2016 gave the MSX125 an even sharper new attitude with an enhanced design that projects a streetfighter feel.

Now with more angular design lines, unique stacked LED headlight and a compact, under-slung exhaust.

The MSX125 is part mini-bike part motorcycle featuring well-proven and efficient 125cc fuel-injected engine for consistent power delivery.

SMALL IN APPEARANCE, LARGE IN IMPACT

During the original development of the MSX125, four patents were applied for which were focussed on the split structure tank cover and frame. This rectifies the seriousness with which Honda created this new model.

Model Specification


  • Engine

    Engine Type

    Air-cooled 2-valve single cylinder

    Engine Displacement

    124.9

    Bore and Stroke

    52.4 x 57.9

    Carburation

    PGM-FI electronic fuel injection

    Compression Ratio

    9.3:1

    Ignition

    Starter

    Electric

    Oil Capacity

    1.1

  • Performance

    Max Torque

    10.9Nm / 5,500rpm (95/1/EC)

    Max Power

    7.2kW / 7,000 rpm (95/1/EC)

  • Dimensions

    Length x Width x Height

    1760 x 755 x 1010

    Wheelbase

    1200

    Ground Clearance

    160

    Seat Height

    765

    Fuel Capacity

    5.5 litres

    Tyres Front

    120/70-12

    Tyres Rear

    130/70-12

    Brakes Front

    ABS - Single 220mm disc with hydraulic dual-piston brake caliper

    Brakes Rear

    Single 190mm disc with hydraulic single-piston brake caliper

    Dimensions

    Kerb Weight

    101.7

    Dry Weight

  • Wheels

    Suspension Front

    USD Front Forks, 31mm

    Suspension Rear

    Mono shock, steel square pipe swingarm

    Wheels Front

    Y-Spoke Aluminium Cast MT 2.5 -12

    Wheels Rear

    Y-Spoke Aluminium Cast MT 2.5 -12

  • Transmission

    Transmission

    Gearbox

    4-speed

    Final Drive

    Chain

    Transmission Type

  • Frame

    Frame Type

    Steel mono-backbone frame
