Model Description


THE PERFECT PARTNER </h3

Ready for the city.
Based on the hugely popular SH125i, the compact size, smart bodywork and low running costs make the SH Mode 125 the perfect partner for busy urban life.

It’s all-new, too. Fully refreshed styling makes a self-assured statement of subtle elegance, with a premium LED headlight and extra leg room. There’s also more storage space under the seat, and a glovebox with USB Type-C socket. And, for one less thing to think about, we’ve added Smart Key operation – so you put the key in your pocket and ride.

SH STYLE & PRACTICALITY

It’s true, the sculpted lines of the SH Mode 125 make quite an impression. But, because it’s a member of our SH family, beautiful form also incorporates a great deal of practical functionality. The spacious flat floor features more leg room; there is also room for a full-face helmet under the seat and a handy glovebox with USB Type-C socket in the fairing, to keep your smartphone charging while you ride. For confident easy handling, supple suspension and cast aluminium 16-inch front and 14-inch rear wheels combine to smooth out rough city tarmac.

Model Specification


  • Engine

    Engine Type

    Single-cylinder, liquid cooled, SOHC 4-stroke

    Engine Displacement

    125cc

    Bore and Stroke

    53.5 × 55.5mm

    Carburation

    PGM-FI electronic fuel injection

    Compression Ratio

    11.5 :1

    Ignition

    Starter

    Electric

    Oil Capacity

    0.9L

  • Performance

    Max Torque

    12.1Nm / 5000rpm

    Max Power

    8.4 kW / 8,750rpm

  • Dimensions

    Length x Width x Height

    Wheelbase

    1305 mm

    Ground Clearance

    150 mm

    Seat Height

    765 mm

    Fuel Capacity

    5.5 litres

    Tyres Front

    80/90-16M/C 43P

    Tyres Rear

    100/90-14M/C 57P

    Brakes Front

    220mm hydraulic disc

    Brakes Rear

    130mm drum

    Dimensions

    Kerb Weight

    118 kg

    Dry Weight

  • Wheels

    Suspension Front

    Telescopic

    Suspension Rear

    Unit swingarm

    Wheels Front

    Cast aluminium 16M/CXMT2.15

    Wheels Rear

    Cast aluminium 14M/CXMT2.75

  • Transmission

    Transmission

    Gearbox

    Final Drive

    V-Belt

    Transmission Type

    CVT

  • Frame

    Frame Type

    Under bone
