Model Description


GSX-S ENGINE

There is a science to building high-performance engines and the GSX-S125’s single cylinder, liquid cooled, DOHC (Double Over Head Cam) is a perfect example of how to make a lot of power out of a very efficient and compact power plant. This power combines with strong torque and exceptional fuel economy, to create an engine worthy of the GSX-S marque, it powers the GSX-S to great performance on the streets and a lot more.

Model Specification


  • Engine

    Engine Type

    4-stroke, 1-cylinder, liquid-cooled, DOHC

    Engine Displacement

    Fuel System

    Fuel Injection

    Ignition

    Electronic ignition

    Lubrication

    Wet sump

    Transmission

    6-speed, constant mesh

    Final Drive

    Chain

    Fuel Capacity

    11.0 litres (2.4UK gallons)

  • Dimensions

    Bore x Stroke

    62.0mm x 41.2mm (2.4in x 1.6in)

    Compression Ratio

    11.0 : 1

    Length

    2000mm (78.7in)

    Width

    745mm (29.33in)

    Height

    1035mm (40.7in)

    Wheelbase

    1300mm (51.18in)

    Seat Height

    785mm (30.91in)

  • Frame

    Tyres Front

    90/80-17M/C

    Tyres Rear

    130/70-17M/C

    Kerb Mass

    133.0kg (293.21lbs)

  • Performance

    Brakes Front

    Disc (Petal)

    Brakes Rear

    Disc (Petal)

  • Suspension

    Suspension Front

    Telescopic, coil spring, oil damped

    Suspension Rear

    Link type, coil spring, oil damped
