Model Description


V-TWIN

The V-Twin engine is a marvel of engineering with superb versatility. While at lower RPM, this engine delivers powerful torque that’s easy to handle and a deep robust sound. Open the throttle to mid-range, and the power of the engine’s response is linear and smooth, yet always under your control. Then at higher RPM, the V-Twin has performance ready to go.

Model Specification


  • Engine

    Engine Type

    4-stroke, 2-cylinder, liquid-cooled, DOHC, 90°V-twin

    Engine Displacement

    Fuel System

    Fuel injection

    Ignition

    Electronic ignition (Transistorised)

    Lubrication

    Wet sump

    Transmission

    6-speed constant mesh

    Final Drive

    Chain

    Fuel Capacity

    14.5 litres (3.2 UK gallons)

  • Dimensions

    Bore x Stroke

    81 mm x 62.6 mm (3.2 in x 2.5 in)

    Compression Ratio

    11.2 : 1

    Length

    2140 mm (84.3 in)

    Width

    730 mm (28.7 in)

    Height

    1090 mm (42.9 in)

    Wheelbase

    1445 mm (56.9 in)

    Seat Height

    790 mm (31.1 in)

  • Frame

    Tyres Front

    120/70ZR17M/C (58W), tubeless

    Tyres Rear

    160/60ZR17M/C (69W), tubeless

    Kerb Mass

    198.0 kg (437 lbs)

  • Performance

    Brakes Front

    Disc brake, twin

    Brakes Rear

    Disc brake

  • Suspension

    Suspension Front

    Telescopic, coil spring, oil damped, spring preload adjustable

    Suspension Rear

    Link type, coil spring, oil damped, spring preload adjustable
